MX Series
Dye Fixation
Dye Fixation Calender
The MX Series is an industrial calender family that performs post-print fixation — chemically bonding the dye to the fibre after digital textile printing. It sits at the exit of the digital print line, applying heat and pressure to already-printed fabric. It handles three main dye classes: reactive dyes (cotton, viscose, linen), acid dyes (wool, silk, nylon) and disperse dyes (polyester). Each class requires a different temperature and dwell time; the operator selects the right profile for the fabric type. For digital textile printing plants, fashion and home-textile exporters, and flag / banner producers, MX is the machine that closes the digital printing line.
Air Shaft (2 pcs)
Pneumatic shaft that locks rolls on the mandrel. Inflates and deflates for fast roll change with no slip under tension.
Anti-Static Bar
Ionises and neutralises built-up static. Reduces dust adhesion on thin fabrics and plastic wrapping.
External Special Steam Boiler Unit
Dedicated steam system that boosts fixation quality. Preferred on reactive and acid dye lines.
Fabric Straightener Roller
A bar mounted mid-machine that lets the operator set input-fabric tension.
Front Walking Platform
Feeds paper and fabric below the platform. Gives the operator room to work and move in front of the machine.
Pneumatic Ventilation Hood Over the Drum
Pneumatic hood mounted over the drum. Draws fumes at the source during fixation.
UPS Power Supply
Takes over on mains cut-out. The felt keeps moving so it does not scorch at a fixed point on the hot drum.
Air Shaft
Pneumatic shaft. Inflates and deflates so the roll grips the mandrel and changes quickly.
Ø 320mm· 4 models · 1900-3300 mm+
Ø 1000mm· 4 models · 1900-3300 mm+
MX-190W-320D· Ø320mm (12.60″) · 1900mm (74.80″)+
- Supply voltage
- 380 - 415 VAC
- Frequency
- 50 / 60 Hz
- Phases
- 3 Phase
- Electrical Connection Type
- 3PH + N + PE (E)
- Total installed power
- 24 kW
- Total Current
- 36,5 A
- Resistance Power
- 23,5 kW
- Resistance Current
- 35,5 A
- Main Line Cable Section
- 5 × 6 mm²
- Emergency stop
- 4 Emergency Stop Buttons
- Warranty
- 6000 h / 1 Year
- Heating Line Protection Switch
- Yes
- Over-Temperature Protection
- Yes (240 °C)
- Contactor Failure Protection
- Yes
- Audible Alarm
- Buzzer
- Visual Alarm
- Yellow Warning Lamp
- Phase Protection Relay
- Yes
- Fuse Protection
- Yes
- Grounding Protection
- Yes
- Heating system
- Oil-Heated Drum
- Max operating temperature
- 230 °C
- Average Heating Time
- 90 min
- Average Cooling Time
- 180 - 300 min
- Air Pressure
- 5 - 8 BAR
- Electrical System
- Automatic Control Circuit
- Speed control
- AC Inverter
- Temperature Control System
- Digital Thermostat
- Temperature Sensor
- Thermocouple
- PLC Safety Monitoring
- Yes
- Sensor Failure Detection
- Yes
- Sensor Cable Break Protection
- Yes
- Drum diameter
- 320 mm
- Drum face width
- 1900 mm
- Effective working width
- 1800 mm
MX-220W-320D· Ø320mm (12.60″) · 2200mm (86.61″)+
- Supply voltage
- 380 - 415 VAC
- Frequency
- 50 / 60 Hz
- Phases
- 3 Phase
- Electrical Connection Type
- 3PH + N + PE (E)
- Total installed power
- 30 kW
- Total Current
- 45,5 A
- Resistance Power
- 28,5 kW
- Resistance Current
- 43 A
- Main Line Cable Section
- 5 × 6 mm²
- Emergency stop
- 4 Emergency Stop Buttons
- Warranty
- 6000 h / 1 Year
- Heating Line Protection Switch
- Yes
- Over-Temperature Protection
- Yes (240 °C)
- Contactor Failure Protection
- Yes
- Audible Alarm
- Buzzer
- Visual Alarm
- Yellow Warning Lamp
- Phase Protection Relay
- Yes
- Fuse Protection
- Yes
- Grounding Protection
- Yes
- Heating system
- Oil-Heated Drum
- Max operating temperature
- 230 °C
- Average Heating Time
- 90 min
- Average Cooling Time
- 180 - 300 min
- Air Pressure
- 5 - 8 BAR
- Electrical System
- Automatic Control Circuit
- Speed control
- AC Inverter
- Temperature Control System
- Digital Thermostat
- Temperature Sensor
- Thermocouple
- PLC Safety Monitoring
- Yes
- Sensor Failure Detection
- Yes
- Sensor Cable Break Protection
- Yes
- Drum diameter
- 320 mm
- Drum face width
- 2200 mm
- Effective working width
- 2100 mm
MX-260W-320D· Ø320mm (12.60″) · 2600mm (102.36″)+
- Supply voltage
- 380 - 415 VAC
- Frequency
- 50 / 60 Hz
- Phases
- 3 Phase
- Electrical Connection Type
- 3PH + N + PE (E)
- Total installed power
- 37 kW
- Total Current
- 56 A
- Resistance Power
- 35 kW
- Resistance Current
- 53 A
- Main Line Cable Section
- 4 × 10 + 6 mm²
- Emergency stop
- 4 Emergency Stop Buttons
- Warranty
- 6000 h / 1 Year
- Heating Line Protection Switch
- Yes
- Over-Temperature Protection
- Yes (240 °C)
- Contactor Failure Protection
- Yes
- Audible Alarm
- Buzzer
- Visual Alarm
- Yellow Warning Lamp
- Phase Protection Relay
- Yes
- Fuse Protection
- Yes
- Grounding Protection
- Yes
- Heating system
- Oil-Heated Drum
- Max operating temperature
- 230 °C
- Average Heating Time
- 90 min
- Average Cooling Time
- 180 - 300 min
- Air Pressure
- 5 - 8 BAR
- Electrical System
- Automatic Control Circuit
- Speed control
- AC Inverter
- Temperature Control System
- Digital Thermostat
- Temperature Sensor
- Thermocouple
- PLC Safety Monitoring
- Yes
- Sensor Failure Detection
- Yes
- Sensor Cable Break Protection
- Yes
- Drum diameter
- 320 mm
- Drum face width
- 2600 mm
- Effective working width
- 2500 mm
MX-330W-320D· Ø320mm (12.60″) · 3300mm (129.92″)+
- Supply voltage
- 380 - 415 VAC
- Frequency
- 50 / 60 Hz
- Phases
- 3 Phase
- Electrical Connection Type
- 3PH + N + PE (E)
- Total installed power
- 47 kW
- Total Current
- 71,5 A
- Resistance Power
- 45 kW
- Resistance Current
- 68,5 A
- Main Line Cable Section
- 4 × 16 + 10 mm²
- Emergency stop
- 4 Emergency Stop Buttons
- Warranty
- 6000 h / 1 Year
- Heating Line Protection Switch
- Yes
- Over-Temperature Protection
- Yes (240 °C)
- Contactor Failure Protection
- Yes
- Audible Alarm
- Buzzer
- Visual Alarm
- Yellow Warning Lamp
- Phase Protection Relay
- Yes
- Fuse Protection
- Yes
- Grounding Protection
- Yes
- Heating system
- Oil-Heated Drum
- Max operating temperature
- 230 °C
- Average Heating Time
- 90 min
- Average Cooling Time
- 180 - 300 min
- Air Pressure
- 5 - 8 BAR
- Electrical System
- Automatic Control Circuit
- Speed control
- AC Inverter
- Temperature Control System
- Digital Thermostat
- Temperature Sensor
- Thermocouple
- PLC Safety Monitoring
- Yes
- Sensor Failure Detection
- Yes
- Sensor Cable Break Protection
- Yes
- Drum diameter
- 320 mm
- Drum face width
- 3300 mm
- Effective working width
- 3200 mm
MX-220W-1000D· Ø1000mm (39.37″) · 2200mm (86.61″)+
- Supply voltage
- 380 - 415 VAC
- Frequency
- 50 / 60 Hz
- Phases
- 3 Phase
- Electrical Connection Type
- 3PH + N + PE
- Total installed power
- 60,2 kW
- Total Current
- 91,5 A
- Resistance Power
- 58 kW
- Resistance Current
- 88,2 A
- Main Line Cable Section
- 4 × 25 + 10 mm²
- Emergency stop
- 4 Emergency Stop Buttons
- Warranty
- 6000 h / 1 Year
- Heating Line Protection Switch
- Yes
- Over-Temperature Protection
- Yes (240 °C)
- Contactor Failure Protection
- Yes
- Audible Alarm
- Buzzer
- Visual Alarm
- Yellow Warning Lamp
- Phase Protection Relay
- Yes
- Fuse Protection
- Yes
- Grounding Protection
- Yes
- Heating system
- Oil-Heated Drum
- Max operating temperature
- 230 °C
- Average Heating Time
- 90 - 120 min
- Average Cooling Time
- 180 - 300 min
- Air Pressure
- 5 - 8 BAR
- Electrical System
- Industrial control circuit
- Speed control
- AC Inverter
- Temperature Control System
- Digital Thermostat
- Temperature Sensor
- Thermocouple
- PLC Safety Monitoring
- Yes
- Sensor Failure Detection
- Yes
- Sensor Cable Break Protection
- Yes
- Drum diameter
- 1000 mm
- Drum face width
- 2200 mm
- Effective working width
- 2100 mm
