MM Series
Mid-Capacity · Piece & Roll
Mid-Capacity Sublimation Calender
The MM Series is a sublimation calender built for mid-volume production. A wider drum diameter than the compact class and PLC touchscreen control deliver faster, more consistent prints. The same machine handles both piece and roll fabric — covering a broad product range from sportswear, scarves and t-shirts to cushion covers, banners and flags. Workshops that started production on MC and have grown choose MM as the natural step before moving to industrial-scale machines. Two working-width options let you match the machine to your floor space and product mix.
Glass Table
4 mm tempered glass, aluminium frame. Fabric lays flat on a level surface — fast, accurate alignment.
Air Shaft (2 pcs)
Pneumatic shaft that locks rolls on the mandrel. Inflates and deflates for fast roll change with no slip under tension.
Drum Scraping Unit
Scrapes off dust, lint and dye residue that stick to the drum surface during operation. Print quality stays consistent through the shift.
Anti-Static Bar
Ionises and neutralises built-up static. Reduces dust adhesion on thin fabrics and plastic wrapping.
Remote Access Ethernet Module
Remote-access link over the PLC network. Our service team diagnoses issues without visiting the site.
Ventilation Hood
Extracts sublimation fumes from above the machine and vents them outside. Keeps the workshop air clean.
UPS Power Supply
Takes over on mains cut-out. The felt keeps moving so it does not scorch at a fixed point on the hot drum.
Air Shaft
Pneumatic shaft. Inflates and deflates so the roll grips the mandrel and changes quickly.
MM-170W-320D· Ø320mm (12.60″) · 1700mm (66.93″)+
- Supply voltage
- 380 - 415 VAC
- Frequency
- 50 / 60 Hz
- Phases
- 3 Phase
- Electrical Connection Type
- 3PH + N + PE (E)
- Total installed power
- 20 kW
- Total Current
- 31 A
- Resistance Power
- 18,5 kW
- Resistance Current
- 28 A
- Main Line Cable Section
- 5 × 6 mm²
- UPS Connection Input
- Present (L - N 200-240 VAC 10A)
- Emergency stop
- 4 Emergency Stop Buttons
- Warranty
- 6000 h / 1 Year
- Heating Line Protection Switch
- Yes
- Over-Temperature Protection
- Yes (240 °C)
- Contactor Failure Protection
- Yes
- Audible Alarm
- Buzzer
- Visual Alarm
- Yellow Warning Lamp
- Phase Protection Relay
- Yes
- Fuse Protection
- Yes
- Grounding Protection
- Yes
- Heating system
- Oil-Heated Drum
- Max operating temperature
- 230 °C
- Average Heating Time
- 90 min
- Average Cooling Time
- 180 - 300 min
- Air Pressure
- 5 - 8 BAR
- Felt tension control
- Pneumatic Control
- Felt centering
- Automatic via Limit Switch & Pneumatic Piston
- Production Speed Range
- 0.6 - 8.0 m/min
- Felt Size (Perimeter × Width × Thickness)
- 2220 × 1740 × 8 mmSpare felt
- Electrical System
- PLC Control
- Speed control
- AC Inverter
- Weekly Scheduling
- Yes
- Automatic cool-down
- Yes
- Auto Shutoff After Cooling
- Yes
- Touchscreen
- Yes
- Interface Language
- Turkish, English
- Temperature Control System
- Digital Thermostat
- Temperature Sensor
- Thermocouple
- PLC Safety Monitoring
- Yes
- Sensor Failure Detection
- Yes
- Sensor Cable Break Protection
- Yes
- Installation Dimensions (W × L × H)
- 2676 × 2680 × 1400 mm
- Net Weight
- 1300 kg
- Gross Weight
- 1600 kg
- Package Dimensions (W × L × H)
- 2900 × 1700 × 1850 mm
- Drum diameter
- 320 mm
- Drum face width
- 1700 mm
- Effective working width
- 1600 mm
MM-190W-320D· Ø320mm (12.60″) · 1900mm (74.80″)+
- Supply voltage
- 380 - 415 VAC
- Frequency
- 50 / 60 Hz
- Phases
- 3 Phase
- Electrical Connection Type
- 3PH + N + PE (E)
- Total installed power
- 25 kW
- Total Current
- 38 A
- Resistance Power
- 23,5 kW
- Resistance Current
- 36 A
- Main Line Cable Section
- 5 × 6 mm²
- UPS Connection Input
- Present (L - N 200-240 VAC 10A)
- Emergency stop
- 4 Emergency Stop Buttons
- Warranty
- 6000 h / 1 Year
- Heating Line Protection Switch
- Yes
- Over-Temperature Protection
- Yes (240 °C)
- Contactor Failure Protection
- Yes
- Audible Alarm
- Buzzer
- Visual Alarm
- Yellow Warning Lamp
- Phase Protection Relay
- Yes
- Fuse Protection
- Yes
- Grounding Protection
- Yes
- Heating system
- Oil-Heated Drum
- Max operating temperature
- 230 °C
- Average Heating Time
- 90 min
- Average Cooling Time
- 180 - 300 min
- Air Pressure
- 5 - 8 BAR
- Felt tension control
- Pneumatic Control
- Felt centering
- Automatic via Limit Switch & Pneumatic Piston
- Production Speed Range
- 0.6 - 8.0 m/min
- Electrical System
- PLC Control
- Speed control
- AC Inverter
- Weekly Scheduling
- Yes
- Automatic cool-down
- Yes
- Auto Shutoff After Cooling
- Yes
- Touchscreen
- Yes
- Interface Language
- Turkish, English
- Temperature Control System
- Digital Thermostat
- Temperature Sensor
- Thermocouple
- PLC Safety Monitoring
- Yes
- Sensor Failure Detection
- Yes
- Sensor Cable Break Protection
- Yes
- Installation Dimensions (W × L × H)
- 2880 × 3000 × 1500 mm
- Net Weight
- 1450 kg
- Gross Weight
- 1800 kg
- Package Dimensions (W × L × H)
- 3100 × 1700 × 1850 mm
- Drum diameter
- 320 mm
- Drum face width
- 1900 mm
- Effective working width
- 1800 mm
