Narrow Fabric & Ribbon Sublimation Calender

The MO Series runs sublimation printing on narrow polyester tapes. Multi-lane parallel architecture prints dozens of tapes at the same time: • Ribbons: decorative polyester ribbon, satin ribbon, organza ribbon, gift-wrap tape, grosgrain • Lanyards and ID bands: conference and trade-show lanyards, school and corporate ID bands, event neck straps • Elastic and webbing: underwear waistband, sports band, sock elastic, bed-edge webbing • Woven labels: garment brand labels, care-instruction labels, size labels, logo tapes • Belts and accessories: belt lining, bag straps, shoelaces, watch-strap lining • Safety and industrial: reflective tape, seatbelt webbing, edge-protection tape, military / police ribbon FO is the right fit for producers that do not run wide-format printing but have high narrow-tape volume. For wide-fabric production, MM or MB is a better match.

The MO is not a scaled-down wide-format press. It is a purpose-built narrow-web calender designed around the mechanics of ribbon, tape, elastic and lanyard sublimation — where multiple parallel strips move under tight tension control rather than a single sheet of fabric. Two working widths cover the narrow-web market: MO-050W-320D at 500 mm chassis width for ribbon converters, lanyard printers and flag-trim workshops running promotional tapes up to roughly 400 mm of active transfer, and MO-070W-320D at 700 mm for name-tape producers and decorative trim shops handling parallel ribbon bundles up to roughly 600 mm. Both models share a Ø320 mm oil-heated drum — the same thermal chemistry used on the wider MB and MR lines, scaled for narrow-web dwell. Drum temperature reaches 230 °C with a 240 °C over-temperature cutoff; the short contact arc is balanced against slower PLC-controlled line speed so that elastic, polyester ribbon and woven tape all receive the full transfer cycle without scorching. Power is modest and single-line: 7 kW total on the MO-050W-320D (5.5 kW resistance, 10.5 A) and 9 kW on the MO-070W-320D (8 kW resistance, 13.5 A). Both ship for 3PH + N + PE connection through a 5 × 2.5 mm² supply cable — a standard workshop feed, no plant-class switchgear required. The AC-inverter drive sets line speed against dwell time; weekly scheduling automation lets operators pre-heat the drum before the shift. Felt on the MO-070W-320D measures 2700 × 740 × 8 mm. Pneumatic felt tension and limit-switch centering keep narrow-web tracking stable across long ribbon runs. Net weight is 1070–1200 kg depending on configuration. Compact freight footprint suits workshop installation without crane access.

The electrical and mechanical design of the MO Series includes 13 independent layers of protection. Operator safety • 4 emergency stop buttons • Audible alarm and visual indicator (yellow lamp) Electrical protection • Phase protection — cuts on voltage fluctuation • Fuse protection — isolates on circuit fault • Earth-leakage protection — cuts on residual current • Contactor protection system Thermal protection • Automatic overheat cut-off at 240 °C • Heating-circuit protection Drum safety • Drum pressure-relief system — automatic release on abnormal pressure inside the drum Pneumatic system safety • Air-loss protection — when the compressor fails or air supply stops, the machine auto-detects the lack of pneumatic pressure, drops speed to minimum, and runs the felt forward and backward in short intervals to prevent it from drifting sideways. The felt stays safe until air returns. PLC and sensor reliability • PLC safety monitoring — tracks electrical and mechanical faults centrally • Sensor-fault detection — backup circuit engages if main sensor fails • Sensor-cable protection — safe lockout on mechanical disconnection For warranty, installation and service details, contact our team.

Dedicated engineering for narrow fabric. An architecture designed from scratch for narrow-tape production. Tension control, edge alignment and tape distribution are all tuned to this production type. Multi-lane parallel printing. On a traditional calender, tape production runs in a single line — hourly m² output stays low. On the MO, dozens of tapes print side by side in a single drum pass. Hourly yield can run several times above a wide calender. Tape distribution unit. Each tape is monitored by its own tension sensor; the system sends an automatic alert if a tape drifts or tangles. On narrow fabric, every millimetre of drift means a print error — this unit prevents it. Quick guide-bar changeover. Guide bars can be swapped fast to move between tape widths. In small-batch, many-order workflows, the same machine shifts between products through the day. PLC touchscreen control + recipe memory. Parameter profiles for different tape types and fabric blends are stored. The recipe stays consistent even when operators change. Weekly scheduling + automatic cooldown — time saved. If work starts at 08:00, set the machine to warm up at 07:00 — it is ready by 08:00. At end of shift, one touch puts the machine into automatic cooldown; it shuts down safely once under 90 °C. Automatic resume after power loss. Short interruptions preserve PLC settings; when power returns, the machine picks up where it left off — no separate UPS required. For long outages, a UPS input port is standard for those who want to connect an external UPS. 220V voltage option. In addition to the standard configuration, the machine can be delivered in a 220V build for countries with 220V infrastructure. Specified at order. Compact design. Narrow-fabric factories often work in constrained space; the MO footprint fits comfortably in existing layouts. Internationally readable model code. The MO format directly states working width and drum diameter — a foreign buyer grasps it instantly in the technical catalogue.
