MB Series
Piece & Roll-to-Roll
Industrial Sublimation Calender
The MB Series is a sublimation calender family built for export-volume, multi-shift industrial textile operations. Three drum diameters (Ø400, Ø600, Ø1000 mm) and a wide range of working widths let you pick a configuration that matches your product mix and production volume. Both piece and roll fabric run on the same machine. Applications span wide-format curtain fabric, quilt panels, trade-show banners, automotive interior trim and bulk team-jersey production. For producers scaling up from MM or setting up digital print lines in an industrial facility, MB is the natural ramp. PLC control and a safety architecture built for 24-hour shift operation come standard.
Glass Table
4 mm tempered glass, aluminium frame. Fabric lays flat on a level surface — fast, accurate alignment.
Air Shaft (2 pcs)
Pneumatic shaft that locks rolls on the mandrel. Inflates and deflates for fast roll change with no slip under tension.
Drum Scraping Unit
Scrapes off dust, lint and dye residue that stick to the drum surface during operation. Print quality stays consistent through the shift.
Smoke Suction Unit
Captures the sublimation fumes right where they form — around the drum.
Anti-Static Bar
Ionises and neutralises built-up static. Reduces dust adhesion on thin fabrics and plastic wrapping.
Remote Access Ethernet Module
Remote-access link over the PLC network. Our service team diagnoses issues without visiting the site.
Ventilation Hood
Extracts sublimation fumes from above the machine and vents them outside. Keeps the workshop air clean.
UPS Power Supply
Takes over on mains cut-out. The felt keeps moving so it does not scorch at a fixed point on the hot drum.
Table Conveyor Belt Unit
Feeds fabric and paper into the machine automatically. No manual lifting, no broken flow.
External Fabric Windup Unit
Winds the printed fabric on a separate unit. Cools better and frees space around the machine.
Additional Digital Paper Feeding Shaft With Manual Brake
Keeps a spare paper roll ready. When the main roll runs out, you switch without stopping the machine.
Crushing Roller Over Drum
Extra roller mounted over the drum. Applies compression for lamination on heavy or technical fabrics.
Air Shaft
Pneumatic shaft. Inflates and deflates so the roll grips the mandrel and changes quickly.
Ø 400mm· 5 models · 1900-4400 mm+
Ø 600mm· 5 models · 1900-4400 mm+
Ø 1000mm· 5 models · 1900-4400 mm+
MB-190W-400D· Ø400mm (15.75″) · 1900mm (74.80″)+
- Supply voltage
- 380 - 415 VAC
- Frequency
- 50 / 60 Hz
- Phases
- 3 Phase
- Electrical Connection Type
- 3PH + N + PE (E)
- Total installed power
- 33 kW
- Total Current
- 50 A
- Resistance Power
- 31,5 kW
- Resistance Current
- 48 A
- Main Line Cable Section
- 4 × 10 + 6 mm²
- UPS Connection Input
- Present (L - N 200-240 VAC 10A)
- Emergency stop
- 4 emergency stop buttons + safety rope
- Warranty
- 6000 h / 1 Year
- Heating Line Protection Switch
- Yes
- Over-Temperature Protection
- Yes (240 °C)
- Contactor Failure Protection
- Yes
- Audible Alarm
- Buzzer
- Visual Alarm
- Yellow Warning Lamp
- Phase Protection Relay
- Yes
- Fuse Protection
- Yes
- Grounding Protection
- Yes
- Heating system
- Oil-Heated Drum
- Max operating temperature
- 230 °C
- Average Heating Time
- 90 min
- Average Cooling Time
- 180 - 300 min
- Air Pressure
- 5 - 8 BAR
- Felt tension control
- Pneumatic Control
- Felt centering
- Automatic via Limit Switch & Pneumatic Piston
- Production Speed Range
- 0.6 - 10.0 m/min
- Felt Size (Perimeter × Width × Thickness)
- 2740 × 1940 × 8 mmSpare felt
- Bottom Belt (Front) Dimensions
- 1900 × 2025 mm
- Bottom Belt (Rear) Dimensions
- 1900 × 2025 mm
- Table Conveyor Belt Dimensions
- 2200 × 1930 mm
- Electrical System
- PLC Control
- Speed control
- AC Inverter
- Weekly Scheduling
- Yes
- Automatic cool-down
- Yes
- Auto Shutoff After Cooling
- Yes
- Touchscreen
- Yes
- Interface Language
- Turkish, English
- Temperature Control System
- Digital Thermostat
- Temperature Sensor
- Thermocouple
- PLC Safety Monitoring
- Yes
- Sensor Failure Detection
- Yes
- Sensor Cable Break Protection
- Yes
- Installation Dimensions (W × L × H)
- 3105 × 4174 × 1770 mm
- Net Weight
- 2350 kg
- Gross Weight
- 2700 kg
- Package Dimensions (W × L × H)
- 3250 × 2300 × 2050 mm
- Drum diameter
- 400 mm
- Drum face width
- 1900 mm
- Effective working width
- 1800 mm
MB-220W-400D· Ø400mm (15.75″) · 2200mm (86.61″)+
- Supply voltage
- 380 - 415 VAC
- Frequency
- 50 / 60 Hz
- Phases
- 3 Phase
- Electrical Connection Type
- 3PH + N + PE (E)
- Total installed power
- 40 kW
- Total Current
- 61 A
- Resistance Power
- 38,5 kW
- Resistance Current
- 58,5 A
- Main Line Cable Section
- 4 × 10 + 6 mm²
- UPS Connection Input
- Present (L - N 200-240 VAC 10A)
- Emergency stop
- 4 emergency stop buttons + safety rope
- Warranty
- 6000 h / 1 Year
- Heating Line Protection Switch
- Yes
- Over-Temperature Protection
- Yes (240 °C)
- Contactor Failure Protection
- Yes
- Audible Alarm
- Buzzer
- Visual Alarm
- Yellow Warning Lamp
- Phase Protection Relay
- Yes
- Fuse Protection
- Yes
- Grounding Protection
- Yes
- Heating system
- Oil-Heated Drum
- Max operating temperature
- 230 °C
- Average Heating Time
- 90 min
- Average Cooling Time
- 300 min
- Air Pressure
- 5 - 8 BAR
- Felt tension control
- Pneumatic Control
- Felt centering
- Automatic via Limit Switch & Pneumatic Piston
- Production Speed Range
- 0.6 - 10.0 m/min
- Electrical System
- PLC Control
- Speed control
- AC Inverter
- Weekly Scheduling
- Yes
- Automatic cool-down
- Yes
- Auto Shutoff After Cooling
- Yes
- Touchscreen
- Yes
- Interface Language
- Turkish, English
- Temperature Control System
- Digital Thermostat
- Temperature Sensor
- Thermocouple
- PLC Safety Monitoring
- Yes
- Sensor Failure Detection
- Yes
- Sensor Cable Break Protection
- Yes
- Drum diameter
- 400 mm
- Drum face width
- 2200 mm
- Effective working width
- 2100 mm
MB-260W-400D· Ø400mm (15.75″) · 2600mm (102.36″)+
- Supply voltage
- 380 - 415 VAC
- Frequency
- 50 / 60 Hz
- Phases
- 3 Phase
- Electrical Connection Type
- 3PH + N + PE (E)
- Total installed power
- 55 kW
- Total Current
- 84 A
- Resistance Power
- 53 kW
- Resistance Current
- 80,5 A
- Main Line Cable Section
- 4 × 16 + 6 mm²
- UPS Connection Input
- Present (L - N 200-240 VAC 10A)
- Emergency stop
- 4 emergency stop buttons + safety rope
- Warranty
- 6000 h / 1 Year
- Heating Line Protection Switch
- Yes
- Over-Temperature Protection
- Yes (240 °C)
- Contactor Failure Protection
- Yes
- Audible Alarm
- Buzzer
- Visual Alarm
- Yellow Warning Lamp
- Phase Protection Relay
- Yes
- Fuse Protection
- Yes
- Grounding Protection
- Yes
- Heating system
- Oil-Heated Drum
- Max operating temperature
- 230 °C
- Average Heating Time
- 90 min
- Average Cooling Time
- 300 min
- Air Pressure
- 5 - 8 BAR
- Felt tension control
- Pneumatic Control
- Felt centering
- Automatic via Limit Switch & Pneumatic Piston
- Production Speed Range
- 0.6 - 10.0 m/min
- Electrical System
- PLC Control
- Speed control
- AC Inverter
- Weekly Scheduling
- Yes
- Automatic cool-down
- Yes
- Auto Shutoff After Cooling
- Yes
- Touchscreen
- Yes
- Interface Language
- Turkish, English
- Temperature Control System
- Digital Thermostat
- Temperature Sensor
- Thermocouple
- PLC Safety Monitoring
- Yes
- Sensor Failure Detection
- Yes
- Sensor Cable Break Protection
- Yes
- Drum diameter
- 400 mm
- Drum face width
- 2600 mm
- Effective working width
- 2500 mm
MB-330W-400D· Ø400mm (15.75″) · 3300mm (129.92″)+
- Supply voltage
- 380 - 415 VAC
- Frequency
- 50 / 60 Hz
- Phases
- 3 Phase
- Electrical Connection Type
- 3PH + N + PE (E)
- Total installed power
- 62 kW
- Total Current
- 94,5 A
- Resistance Power
- 60 kW
- Resistance Current
- 91 A
- Main Line Cable Section
- 4 × 25 + 16 mm²
- UPS Connection Input
- Present (L - N 200-240 VAC 10A)
- Emergency stop
- 4 emergency stop buttons + safety rope
- Warranty
- 6000 h / 1 Year
- Heating Line Protection Switch
- Yes
- Over-Temperature Protection
- Yes (240 °C)
- Contactor Failure Protection
- Yes
- Audible Alarm
- Buzzer
- Visual Alarm
- Yellow Warning Lamp
- Phase Protection Relay
- Yes
- Fuse Protection
- Yes
- Grounding Protection
- Yes
- Heating system
- Oil-Heated Drum
- Max operating temperature
- 230 °C
- Average Heating Time
- 90 min
- Average Cooling Time
- 180 - 300 min
- Air Pressure
- 5 - 8 BAR
- Felt tension control
- Pneumatic Control
- Felt centering
- Automatic via Limit Switch & Pneumatic Piston
- Production Speed Range
- 0.6 - 10.0 m/min
- Electrical System
- PLC Control
- Speed control
- AC Inverter
- Weekly Scheduling
- Yes
- Automatic cool-down
- Yes
- Auto Shutoff After Cooling
- Yes
- Touchscreen
- Yes
- Interface Language
- Turkish, English
- Temperature Control System
- Digital Thermostat
- Temperature Sensor
- Thermocouple
- PLC Safety Monitoring
- Yes
- Sensor Failure Detection
- Yes
- Sensor Cable Break Protection
- Yes
- Drum diameter
- 400 mm
- Drum face width
- 3300 mm
- Effective working width
- 3200 mm
MB-190W-600D· Ø600mm (23.62″) · 1900mm (74.80″)+
- Supply voltage
- 380 - 415 VAC
- Frequency
- 50 / 60 Hz
- Phases
- 3 Phase
- Electrical Connection Type
- 3PH + N + PE (E)
- Total installed power
- 43 kW
- Total Current
- 65,5 A
- Resistance Power
- 41,5 kW
- Resistance Current
- 63 A
- Main Line Cable Section
- 4 × 16 + 10 mm²
- UPS Connection Input
- Present (L - N 200-240 VAC 10A)
- Emergency stop
- 4 emergency stop buttons + safety rope
- Warranty
- 6000 h / 1 Year
- Heating Line Protection Switch
- Yes
- Over-Temperature Protection
- Yes (240 °C)
- Contactor Failure Protection
- Yes
- Audible Alarm
- Buzzer
- Visual Alarm
- Yellow Warning Lamp
- Phase Protection Relay
- Yes
- Fuse Protection
- Yes
- Grounding Protection
- Yes
- Heating system
- Oil-Heated Drum
- Max operating temperature
- 230 °C
- Average Heating Time
- 90 min
- Average Cooling Time
- 180 - 300 min
- Air Pressure
- 5 - 8 BAR
- Felt tension control
- Pneumatic Control
- Felt centering
- Automatic via Limit Switch & Pneumatic Piston
- Production Speed Range
- 0.6 - 10.0 m/min
- Felt Size (Perimeter × Width × Thickness)
- 3470 × 1940 × 8 mmSpare felt
- Bottom Belt (Front) Dimensions
- 2065 × 2025 mm
- Bottom Belt (Rear) Dimensions
- 2065 × 2025 mm
- Table Conveyor Belt Dimensions
- 2200 × 1930 mm
- Electrical System
- PLC Control
- Speed control
- AC Inverter
- Weekly Scheduling
- Yes
- Automatic cool-down
- Yes
- Auto Shutoff After Cooling
- Yes
- Touchscreen
- Yes
- Interface Language
- Turkish, English
- Temperature Control System
- Digital Thermostat
- Temperature Sensor
- Thermocouple
- PLC Safety Monitoring
- Yes
- Sensor Failure Detection
- Yes
- Sensor Cable Break Protection
- Yes
- Installation Dimensions (W × L × H)
- 3100 × 4550 × 1860 mm
- Net Weight
- 3200 kg
- Gross Weight
- 3550 kg
- Package Dimensions (W × L × H)
- 3750 × 2260 × 1984 mm
- Drum diameter
- 600 mm
- Drum face width
- 1900 mm
- Effective working width
- 1800 mm
MB-220W-600D· Ø600mm (23.62″) · 2200mm (86.61″)+
- Supply voltage
- 380 - 415 VAC
- Frequency
- 50 / 60 Hz
- Phases
- 3 Phase
- Electrical Connection Type
- 3PH + N + PE (E)
- Total installed power
- 45 kW
- Total Current
- 68,5 A
- Resistance Power
- 43 kW
- Resistance Current
- 65,5 A
- Main Line Cable Section
- 4 × 16 + 10 mm²
- UPS Connection Input
- Present (L - N 200-240 VAC 10A)
- Emergency stop
- 4 emergency stop buttons + safety rope
- Warranty
- 6000 h / 1 Year
- Heating Line Protection Switch
- Yes
- Over-Temperature Protection
- Yes (240 °C)
- Contactor Failure Protection
- Yes
- Audible Alarm
- Buzzer
- Visual Alarm
- Yellow Warning Lamp
- Phase Protection Relay
- Yes
- Fuse Protection
- Yes
- Grounding Protection
- Yes
- Heating system
- Oil-Heated Drum
- Max operating temperature
- 230 °C
- Average Heating Time
- 90 min
- Average Cooling Time
- 180 - 300 min
- Air Pressure
- 5 - 8 BAR
- Felt tension control
- Pneumatic Control
- Felt centering
- Automatic via Limit Switch & Pneumatic Piston
- Production Speed Range
- 0.6 - 10.0 m/min
- Electrical System
- PLC Control
- Speed control
- AC Inverter
- Weekly Scheduling
- Yes
- Automatic cool-down
- Yes
- Auto Shutoff After Cooling
- Yes
- Touchscreen
- Yes
- Interface Language
- Turkish, English
- Temperature Control System
- Digital Thermostat
- Temperature Sensor
- Thermocouple
- PLC Safety Monitoring
- Yes
- Sensor Failure Detection
- Yes
- Sensor Cable Break Protection
- Yes
- Drum diameter
- 600 mm
- Drum face width
- 2200 mm
- Effective working width
- 2100 mm
MB-260W-600D· Ø600mm (23.62″) · 2600mm (102.36″)+
- Supply voltage
- 380 - 415 VAC
- Frequency
- 50 / 60 Hz
- Phases
- 3 Phase
- Electrical Connection Type
- 3PH + N + PE (E)
- Total installed power
- 56 kW
- Total Current
- 85 A
- Resistance Power
- 53 kW
- Resistance Current
- 80,5 A
- Main Line Cable Section
- 4 × 25 + 16 mm²
- UPS Connection Input
- Present (L - N 200-240 VAC 10A)
- Emergency stop
- 4 emergency stop buttons + safety rope
- Warranty
- 6000 h / 1 Year
- Heating Line Protection Switch
- Yes
- Over-Temperature Protection
- Yes (240 °C)
- Contactor Failure Protection
- Yes
- Audible Alarm
- Buzzer
- Visual Alarm
- Yellow Warning Lamp
- Phase Protection Relay
- Yes
- Fuse Protection
- Yes
- Grounding Protection
- Yes
- Heating system
- Oil-Heated Drum
- Max operating temperature
- 230 °C
- Average Heating Time
- 90 min
- Average Cooling Time
- 180 - 300 min
- Air Pressure
- 5 - 8 BAR
- Felt tension control
- Pneumatic Control
- Felt centering
- Automatic via Limit Switch & Pneumatic Piston
- Production Speed Range
- 0.6 - 10.0 m/min
- Electrical System
- PLC Control
- Speed control
- AC Inverter
- Weekly Scheduling
- Yes
- Automatic cool-down
- Yes
- Auto Shutoff After Cooling
- Yes
- Touchscreen
- Yes
- Interface Language
- Turkish, English
- Temperature Control System
- Digital Thermostat
- Temperature Sensor
- Thermocouple
- PLC Safety Monitoring
- Yes
- Sensor Failure Detection
- Yes
- Sensor Cable Break Protection
- Yes
- Drum diameter
- 600 mm
- Drum face width
- 2600 mm
- Effective working width
- 2500 mm
MB-330W-600D· Ø600mm (23.62″) · 3300mm (129.92″)+
- Supply voltage
- 380 - 415 VAC
- Frequency
- 50 / 60 Hz
- Phases
- 3 Phase
- Electrical Connection Type
- 3PH + N + PE (E)
- Total installed power
- 82 kW
- Total Current
- 124,7 A
- Resistance Power
- 78 kW
- Resistance Current
- 118,6 A
- Main Line Cable Section
- 4 × 35 + 16 mm²
- UPS Connection Input
- Present (L - N 200-240 VAC 10A)
- Emergency stop
- 4 emergency stop buttons + safety rope
- Warranty
- 6000 h / 1 Year
- Heating Line Protection Switch
- Yes
- Over-Temperature Protection
- Yes (240 °C)
- Contactor Failure Protection
- Yes
- Audible Alarm
- Buzzer
- Visual Alarm
- Yellow Warning Lamp
- Phase Protection Relay
- Yes
- Fuse Protection
- Yes
- Grounding Protection
- Yes
- Heating system
- Oil-Heated Drum
- Max operating temperature
- 230 °C
- Average Heating Time
- 90 min
- Average Cooling Time
- 180 - 300 min
- Air Pressure
- 5 - 8 BAR
- Felt tension control
- Pneumatic Control
- Felt centering
- Automatic via Limit Switch & Pneumatic Piston
- Production Speed Range
- 0.6 - 10.0 m/min
- Electrical System
- PLC Control
- Speed control
- AC Inverter
- Weekly Scheduling
- Yes
- Automatic cool-down
- Yes
- Auto Shutoff After Cooling
- Yes
- Touchscreen
- Yes
- Interface Language
- Turkish, English
- Temperature Control System
- Digital Thermostat
- Temperature Sensor
- Thermocouple
- PLC Safety Monitoring
- Yes
- Sensor Failure Detection
- Yes
- Sensor Cable Break Protection
- Yes
- Net Weight
- 5450 kg
- Gross Weight
- 5800 kg
- Package Dimensions (W × L × H)
- 4700 × 2260 × 1990 mm
- Drum diameter
- 600 mm
- Drum face width
- 3300 mm
- Effective working width
- 3200 mm
MB-440W-600D· Ø600mm (23.62″) · 4400mm (173.23″)+
- Supply voltage
- 380 - 415 VAC
- Frequency
- 50 / 60 Hz
- Phases
- 3 Phase
- Electrical Connection Type
- 3PH + N + PE
- Total installed power
- 90,5 kW
- Total Current
- 137,6 A
- Resistance Power
- 2 × 43 = 86 kW
- Resistance Current
- 2 × 65,4 = 130,8 A
- Main Line Cable Section
- 4 × 35 + 16 mm²
- UPS Connection Input
- Included
- Emergency stop
- 4 emergency stop buttons + safety rope
- Warranty
- 6000 h / 1 Year
- Heating Line Protection Switch
- Yes
- Over-Temperature Protection
- Yes (240 °C)
- Contactor Failure Protection
- Yes
- Audible Alarm
- Buzzer
- Visual Alarm
- Yellow Warning Lamp
- Phase Protection Relay
- Yes
- Fuse Protection
- Yes
- Grounding Protection
- Yes
- Heating system
- Oil-Heated Drum
- Max operating temperature
- 230 °C
- Average Heating Time
- 90 - 150 min
- Average Cooling Time
- 180 - 300 min
- Air Pressure
- 5 - 8 BAR
- Felt tension control
- Pneumatic piston
- Felt centering
- Automatic via limit switches and pneumatic system
- Production Speed Range
- 0.6 - 12.0 m/min
- Electrical System
- PLC Control
- Speed control
- AC Inverter
- Weekly Scheduling
- Yes
- Automatic cool-down
- Yes
- Auto Shutoff After Cooling
- Yes
- Touchscreen
- Yes
- Interface Language
- Turkish, English
- Temperature Control System
- Digital Thermostat
- Temperature Sensor
- Thermocouple
- PLC Safety Monitoring
- Yes
- Sensor Failure Detection
- Yes
- Sensor Cable Break Protection
- Yes
- Drum diameter
- 600 mm
- Drum face width
- 4400 mm
- Effective working width
- 4300 mm
MB-190W-1000D· Ø1000mm (39.37″) · 1900mm (74.80″)+
- Supply voltage
- 380 - 415 VAC
- Frequency
- 50 / 60 Hz
- Phases
- 3 Phase
- Electrical Connection Type
- 3PH + N + PE (E)
- Total installed power
- 71 kW
- Total Current
- 108 A
- Resistance Power
- 68 kW
- Resistance Current
- 103,5 A
- Main Line Cable Section
- 4 × 35 + 16 mm²
- UPS Connection Input
- Present (L - N 200-240 VAC 10A)
- Emergency stop
- 4 emergency stop buttons + safety rope
- Warranty
- 6000 h / 1 Year
- Heating Line Protection Switch
- Yes
- Over-Temperature Protection
- Yes (240 °C)
- Contactor Failure Protection
- Yes
- Audible Alarm
- Buzzer
- Visual Alarm
- Yellow Warning Lamp
- Phase Protection Relay
- Yes
- Fuse Protection
- Yes
- Grounding Protection
- Yes
- Heating system
- Oil-Heated Drum
- Max operating temperature
- 230 °C
- Average Heating Time
- 90 min
- Average Cooling Time
- 180 - 300 min
- Air Pressure
- 5 - 8 BAR
- Felt tension control
- Pneumatic Control
- Felt centering
- Automatic via Limit Switch & Pneumatic Piston
- Production Speed Range
- 0.6 - 10.0 m/min
- Felt Size (Perimeter × Width × Thickness)
- 5240 × 1940 × 8 mmSpare felt
- Bottom Belt (Front) Dimensions
- 2370 × 2025 mm
- Bottom Belt (Rear) Dimensions
- 2370 × 2025 mm
- Table Conveyor Belt Dimensions
- 2200 × 1930 mm
- Electrical System
- PLC Control
- Speed control
- AC Inverter
- Weekly Scheduling
- Yes
- Automatic cool-down
- Yes
- Auto Shutoff After Cooling
- Yes
- Touchscreen
- Yes
- Interface Language
- Turkish, English
- Temperature Control System
- Digital Thermostat
- Temperature Sensor
- Thermocouple
- PLC Safety Monitoring
- Yes
- Sensor Failure Detection
- Yes
- Sensor Cable Break Protection
- Yes
- Drum diameter
- 1000 mm
- Drum face width
- 1900 mm
- Effective working width
- 1800 mm
MB-220W-1000D· Ø1000mm (39.37″) · 2200mm (86.61″)+
- Supply voltage
- 380 - 415 VAC
- Frequency
- 50 / 60 Hz
- Phases
- 3 Phase
- Electrical Connection Type
- 3PH + N + PE (E)
- Total installed power
- 78 kW
- Total Current
- 118,5 A
- Resistance Power
- 75 kW
- Resistance Current
- 114 A
- Main Line Cable Section
- 4 × 35 + 16 mm²
- UPS Connection Input
- Present (L - N 200-240 VAC 10A)
- Emergency stop
- 4 emergency stop buttons + safety rope
- Warranty
- 6000 h / 1 Year
- Heating Line Protection Switch
- Yes
- Over-Temperature Protection
- Yes (240 °C)
- Contactor Failure Protection
- Yes
- Audible Alarm
- Buzzer
- Visual Alarm
- Yellow Warning Lamp
- Phase Protection Relay
- Yes
- Fuse Protection
- Yes
- Grounding Protection
- Yes
- Heating system
- Oil-Heated Drum
- Max operating temperature
- 230 °C
- Average Heating Time
- 90 min
- Average Cooling Time
- 180 - 300 min
- Air Pressure
- 5 - 8 BAR
- Felt tension control
- Pneumatic Control
- Felt centering
- Automatic via Limit Switch & Pneumatic Piston
- Production Speed Range
- 0.6 - 10.0 m/min
- Electrical System
- PLC Control
- Speed control
- AC Inverter
- Weekly Scheduling
- Yes
- Automatic cool-down
- Yes
- Auto Shutoff After Cooling
- Yes
- Touchscreen
- Yes
- Interface Language
- Turkish, English
- Temperature Control System
- Digital Thermostat
- Temperature Sensor
- Thermocouple
- PLC Safety Monitoring
- Yes
- Sensor Failure Detection
- Yes
- Sensor Cable Break Protection
- Yes
- Drum diameter
- 1000 mm
- Drum face width
- 2200 mm
- Effective working width
- 2100 mm
MB-260W-1000D· Ø1000mm (39.37″) · 2600mm (102.36″)+
- Supply voltage
- 380 - 415 VAC
- Frequency
- 50 / 60 Hz
- Phases
- 3 Phase
- Electrical Connection Type
- 3PH + N + PE (E)
- Total installed power
- 71 kW
- Total Current
- 108 A
- Resistance Power
- 67 kW
- Resistance Current
- 101,9 A
- Main Line Cable Section
- 4 × 25 + 16 mm²
- UPS Connection Input
- Present (L - N 200-240 VAC 10A)
- Emergency stop
- 4 emergency stop buttons + safety rope
- Warranty
- 6000 h / 1 Year
- Heating Line Protection Switch
- Yes
- Over-Temperature Protection
- Yes (240 °C)
- Contactor Failure Protection
- Yes
- Audible Alarm
- Buzzer
- Visual Alarm
- Yellow Warning Lamp
- Phase Protection Relay
- Yes
- Fuse Protection
- Yes
- Grounding Protection
- Yes
- Heating system
- Oil-Heated Drum
- Max operating temperature
- 230 °C
- Average Heating Time
- 90 min
- Average Cooling Time
- 180 - 300 min
- Air Pressure
- 5 - 8 BAR
- Felt tension control
- Pneumatic Control
- Felt centering
- Automatic via Limit Switch & Pneumatic Piston
- Production Speed Range
- 0.6 - 10.0 m/min
- Electrical System
- PLC Control
- Speed control
- AC Inverter
- Weekly Scheduling
- Yes
- Automatic cool-down
- Yes
- Auto Shutoff After Cooling
- Yes
- Touchscreen
- Yes
- Interface Language
- Turkish, English
- Temperature Control System
- Digital Thermostat
- Temperature Sensor
- Thermocouple
- PLC Safety Monitoring
- Yes
- Sensor Failure Detection
- Yes
- Sensor Cable Break Protection
- Yes
- Drum diameter
- 1000 mm
- Drum face width
- 2600 mm
- Effective working width
- 2500 mm
MB-330W-1000D· Ø1000mm (39.37″) · 3300mm (129.92″)+
- Supply voltage
- 380 - 415 VAC
- Frequency
- 50 / 60 Hz
- Phases
- 3 Phase
- Electrical Connection Type
- 3PH + N + PE (E)
- Total installed power
- 82 kW
- Total Current
- 124,7 A
- Resistance Power
- 78 kW
- Resistance Current
- 118,6 A
- Main Line Cable Section
- 4 × 35 + 16 mm²
- UPS Connection Input
- Present (L - N 200-240 VAC 10A)
- Emergency stop
- 4 emergency stop buttons + safety rope
- Warranty
- 6000 h / 1 Year
- Heating Line Protection Switch
- Yes
- Over-Temperature Protection
- Yes (240 °C)
- Contactor Failure Protection
- Yes
- Audible Alarm
- Buzzer
- Visual Alarm
- Yellow Warning Lamp
- Phase Protection Relay
- Yes
- Fuse Protection
- Yes
- Grounding Protection
- Yes
- Heating system
- Oil-Heated Drum
- Max operating temperature
- 230 °C
- Average Heating Time
- 90 min
- Average Cooling Time
- 180 - 300 min
- Air Pressure
- 5 - 8 BAR
- Felt tension control
- Pneumatic Control
- Felt centering
- Automatic via Limit Switch & Pneumatic Piston
- Production Speed Range
- 0.6 - 10.0 m/min
- Electrical System
- PLC Control
- Speed control
- AC Inverter
- Weekly Scheduling
- Yes
- Automatic cool-down
- Yes
- Auto Shutoff After Cooling
- Yes
- Touchscreen
- Yes
- Interface Language
- Turkish, English
- Temperature Control System
- Digital Thermostat
- Temperature Sensor
- Thermocouple
- PLC Safety Monitoring
- Yes
- Sensor Failure Detection
- Yes
- Sensor Cable Break Protection
- Yes
- Drum diameter
- 1000 mm
- Drum face width
- 3300 mm
- Effective working width
- 3200 mm
The product video will be added shortly. In the meantime, request a live demo over WhatsApp.
Ready to configure your line?
Send your production width, substrate and target throughput — we reply within one business day with a tailored quote, drawings and delivery timeline.
